The TSC TDP-225W printer can print both bracelets and folded, pre-cut, die-cut, continuous roll or black-marked labels at a speed of 127mm/s text, images and barcodes at a resolution of 203 DPI.

Printing method: direct thermal (without ribbon)

Interface: USB and Ethernet

Print speed: 127 mm/s

Print resolution: 203 DPI

Memory: 4 MB Flash, 8 MB SDRAM

DisplayLCD 128 x 64 pixels, with backlight

Printable area: 52 mm

Consumable characteristics: paper width: 52 mm (52 ​​mm printable area)

paper thickness: 0.06 ~ 0.19 mm

external diameter of the roll: 165 mm maximum

core diameter: 25.4 mm (1")

Supported barcodes: 1D: Code 39, Code 93, Code 128UCC, Code 128 subsets A, B, C, Codabar, Interleave 2 of 5, EAN-8, EAN-13, EAN-128, UPC-A, UPC- E, EAN and UPC 2 (5) digits add-on, MSI, PLESSEY, POSTNET, China POST, GS1 DataBar, Code 11

2D: PDF-417, Maxicode, DataMatrix, QR code, Aztec

Software included BarTender labeling software

Power source: external, included in the price of the printer, AC 100-240V, 1A, 47-63Hz; DC 24V, 2.08A, 50W

Dimensions: 109 x 210 x 260 mm

Weight: 1.2 kg

White color

Operating temperature: 5°C – 40°C

humidity: 25 - 85%
