Datalogic’s RIDA™ DBT6400 cordless imager with Bluetooth® wireless technology is the ideal workmate for connection with mobile devices. The imager is a small, ergonomic, perfectly hand-fitted wireless device with a modern and elegant design.

Bluetooth wireless technology Protocol: Bluetooth 4.0 Certified Class 2

Radio Frequency: 2.4 ghz

Radio Range (Open Air): 25.0 m / 82.0 ft

1D / linear codes: Auto discriminates all standard 1D codes including GS1 databar™ linear codes

2D codes: Aztec Code, Aztec Mesas, Data Matrix, maxicode, QR Code, Micro QR Code, China Han Xin Code

Battery Type: Lithium-Ion 700 mah

Charge Time: 2.5 hours when placed in the Base

Station or when the Host is powered through the micro USB cable connection

Reads per Charge: 3,000 + readings or 5 hours (1 read every 6 seconds)

Input Voltage: 5 VDC +/- 5%

Ambient Light: 0 - 100,000 lux

Drop Resistance: Withstands repeated drops from 1.5 m / 5.0 ft onto a concrete surface

Esd Protection (Air Discharge): 16 kv

Humidity (Non-Condensing): 5 - 95%

Particulate And Water Sealing: IP50

Temperature Operating: 0 to 50 °C / 32 to 122 °F

Storage/Transport: -20 to 70 °C / -4 to 158 °F

Interfaces: USB COM, USB-OEM, USB Keyboard (with BC6020

Only)

Image capture: Graphic Formats: BMP, JPEG, TIFF;

Greyscale: 256, 16, 2; JPEG; JPEG, TIFF

Imager sensor Wide VGA: 752 x 480 pixels

Light source Aiming: 650 nm VLD

Illumination: White

Motion tolerance: 25 IPS

Print contrast ratio (minimum): 15%

Reading angle Pitch: +/- 65º; Roll (Tilt): up to 360º;

Skew (Yaw): +/- 60º

Reading indicators Vibration; Beepers, Polyphonic; Datalogic ‘Green

Spot’ Good Read Feedback; Product side and upper

Illumination; Good Read LED

Resolution (maximum): 4 mil

Dimensions: 11.25 x 4.23 x 2.75 cm

Weight With batteries: 85.0 g
